The KY-PZ100 is a robotic pan, tilt and zoom video production camera.
It’s the first PTZ camera that features JVC’s unique IP communications engine providing network connection via WiFi*, 4G-LTE*, or cabled LAN. It’s designed to be used as a stand alone remote camera or as part of a multi-camera system in both studio and field environments. In addition to its 3G-SDI and HDMI outputs, it is also capable of reliably streaming 1080i/60, 1080p, 720p, and 360p video with 2-channel audio–all with minimal latency and forward error correction.
Camera control is possible from a web browser, or with the dedicated RM-LP100 remote control panel, or from a variety of remote units using standard protocol. The camera also includes on-board HD recording at up to 50Mbps to a micro SDHC/SDXC card with the ability to upload the recorded files to an external server.
CAMERA | JVC | KY-PZ100WE | PTZ | Network | Camera
When connected to a Wi-Fi adapter or LTE modem via USB or directly connected to a LAN, the KY-PZ100 streams up to 1080p video with two-channel audio using SMPTE 2022 forward error correction (FEC). The camera offers low latency streaming at various bit rates, and its integrated Zixi technology delivers reliable streaming performance with FEC and automatic repeat request (ARQ), as well as adaptive bit rate control.
Designed as a standalone remote camera or as part of a multi-camera system, the KY-PZ100 can also be used as a conventional PTZ camera. It includes a 1/2.8-inch CMOS sensor (2.1 million pixels) and a 30x optical zoom lens. Its f/1.6-4.7 maximum aperture delivers excellent low-light performance, and its high-sensitivity mode delivers images in darkness as low as 0.01 lux. The camera also supports on-board HD recording at up to 50Mbps to a Micro SDHC/SDXC media card, and recorded files can be uploaded to an external server.
There are many PTZ cameras on the market, but none have a direct host USB connection to an LTE modem or Wi-Fi adapter. This unique capability allows our PTZ camera to be placed anywhere there is a power source and stream broadcast quality HD video. This exciting new technology will appeal to a number of vertical markets including broadcast, government, sports production, and houses of worship.
*WiFi and 4G LTE require optional external adapter
Direct Drive Mechanism
The KY-PZ100 features JVC’s highly accurate direct drive mechanism for smooth, quiet and precise positioning with up to 100 preset positions. Positioning can be performed at a range of speeds from very very slow to very fast while retaining pin-point accuracy (within 0.03°). A newly developed 1/2.8-inch image sensor and 30x optical zoom lens produce superb broadcast quality images even in low light environments. The camera’s Wide Dynamic Range mode provides clear natural foreground images even under challenging highlight conditions.
- 1/2.8-inch CMOS sensor (2.2 million pixels)
- Optical zoom lens with 30x zoom ratio (4.3-129mm, f/1.6~4.7)
- 12x digital zoom
- Autofocus and image stabilization built-in.
- Fast f/1.6-4.7 maximum aperture for excellent low light
- High sensitivity mode (down to 0.01 lux)
- Direct drive motor for smooth, quiet and accurate pan and tilt
- PoE+ equipped: LAN cable enables simultaneous streaming, camera control and power supply
- Full HD 1080p, 1080i, 720p video
- Simultaneous 3G-SDI and HDMI and IP digital outputs
- 2 channels audio (or 1 channel balanced audio)
- USB host connection for WiFi or 4G LTE adapter*
- Advanced IP communications capability:
- Streaming with SMPTE 2022 forward error correction
- Advanced Zixi reliable communication with ARQ, FEC and adaptive bitrate control
- Low latency streaming
- RTMP streaming directly to content delivery network
- (YouTube, Ustream, etc.)
- Micro SDHC/SDXC memory card recording (H.264 50Mbps)
- Remote control via RS-232C / RS-422, or via IP controller
- Can memorize 100 preset settings and positions
- Can be mounted upside-down or right-side-up
Versatile IP Connectivity including Wi-Fi* and 4G/LTE*
The KY-PZ100 is the PTZ camera that features JVC’s unique IP communications engine providing network connection via Wi-Fi*, 4G/LTE*, or wired LAN (*Wi-Fi and 4G/LTE require optional network adapter).
Control from Remote Location with PC
Using a browser, video monitoring and remote camera control can be performed with a PC from all over the world.
RTMP for Direct Streaming to Content Delivery Network
RTMP protocol support enables direct streaming to JVC VIDEOCLOUD, Ustream, YouTube, Facebook, etc. Other various protocols and bitrates are supported for a variety of usages.
